SPP20N60S5 Images
- Manufacturer: Infineon Technologies
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: PG-TO220-3-1
- Description: MOSFET N-CH 650V 20A TO220-3
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
SPP20N60S5 Specifications:
- MfrPart.: SPP20N60S5
- Mfr: Infineon Technologies
- Description: MOSFET N-CH 650V 20A TO220-3
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tube
- Series: CoolMOS™
- PartStatus: Obsolete
- FETType: N-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 650 V
- Current-ContinuousDrain(Id)@25°C: 20A (Tc)
- DriveVoltage(MaxRdsOnMinRdsOn): 10V
- RdsOn(Max)@IdVgs: 190mOhm @ 13A, 10V
- Vgs(th)(Max)@Id: 5.5V @ 1mA
- GateCharge(Qg)(Max)@Vgs: 103 nC @ 10 V
- Vgs(Max): ±20V
- InputCapacitance(Ciss)(Max)@Vds: 3000 pF @ 25 V
- FETFeature: -
- PowerDissipation(Max): 208W (Tc)
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Through Hole
- SupplierDevicePackage: PG-TO220-3-1
- SPP20N60S5 Infineon, MOSFET N-CH 650V 20A TO220-3, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
SPP20N60S5, Infineon authentic parts in stock from Infineon authorized distributors, order today, can ship immediately.
