SPN02N60S5 Images
- Manufacturer: Infineon Technologies
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: PG-SOT223-4
- Description: MOSFET N-CH 600V 400MA SOT223-4
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
SPN02N60S5 Specifications:
- MfrPart.: SPN02N60S5
- Mfr: Infineon Technologies
- Description: MOSFET N-CH 600V 400MA SOT223-4
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tape & Reel (TR)
- Series: CoolMOS™
- PartStatus: Obsolete
- FETType: N-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 600 V
- Current-ContinuousDrain(Id)@25°C: 400mA (Ta)
- DriveVoltage(MaxRdsOnMinRdsOn): 10V
- RdsOn(Max)@IdVgs: 3Ohm @ 1.1A, 10V
- Vgs(th)(Max)@Id: 5.5V @ 80µA
- GateCharge(Qg)(Max)@Vgs: 7.4 nC @ 10 V
- Vgs(Max): ±20V
- InputCapacitance(Ciss)(Max)@Vds: 250 pF @ 25 V
- FETFeature: -
- PowerDissipation(Max): 1.8W (Ta)
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Surface Mount
- SupplierDevicePackage: PG-SOT223-4
- SPN02N60S5 Infineon, MOSFET N-CH 600V 400MA SOT223-4, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
