SIGC156T60NR2CX1SA2 Images
- Manufacturer: Infineon Technologies
- Category: Discrete Semiconductor Products~Transistors - IGBTs - Single Package/Case: Die
- Description: IGBT 3 CHIP 600V WAFER
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
SIGC156T60NR2CX1SA2 Specifications:
- MfrPart.: SIGC156T60NR2CX1SA2
- Mfr: Infineon Technologies
- Description: IGBT 3 CHIP 600V WAFER
- Product Category: Discrete Semiconductor Products~Transistors - IGBTs - Single
- Package: Bulk
- Series: -
- PartStatus: Obsolete
- IGBTType: NPT
- Voltage-CollectorEmitterBreakdown(Max): 600 V
- Current-Collector(Ic)(Max): 200 A
- Current-CollectorPulsed(Icm): 600 A
- Vce(on)(Max)@VgeIc: 2.5V @ 15V, 200A
- Power-Max: -
- SwitchingEnergy: -
- InputType: Standard
- GateCharge: -
- Td(on/off)@25°C: 180ns/285ns
- TestCondition: 300V, 200A, 1.5Ohm, 15V
- ReverseRecoveryTime(trr): -
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Surface Mount
- Package/Case: Die
- SIGC156T60NR2CX1SA2 Infineon, IGBT 3 CHIP 600V WAFER, Discrete Semiconductor Products~Transistors - IGBTs - Single
