SGP10N60AXKSA1 Images
- Manufacturer: Infineon Technologies
- Category: Discrete Semiconductor Products~Transistors - IGBTs - Single Package/Case: TO-220-3
- Description: IGBT 600V 20A 92W TO220-3
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
SGP10N60AXKSA1 Specifications:
- MfrPart.: SGP10N60AXKSA1
- Mfr: Infineon Technologies
- Description: IGBT 600V 20A 92W TO220-3
- Product Category: Discrete Semiconductor Products~Transistors - IGBTs - Single
- Package: Tube
- Series: -
- PartStatus: Obsolete
- IGBTType: NPT
- Voltage-CollectorEmitterBreakdown(Max): 600 V
- Current-Collector(Ic)(Max): 20 A
- Current-CollectorPulsed(Icm): 40 A
- Vce(on)(Max)@VgeIc: 2.4V @ 15V, 10A
- Power-Max: 92 W
- SwitchingEnergy: 320µJ
- InputType: Standard
- GateCharge: 52 nC
- Td(on/off)@25°C: 28ns/178ns
- TestCondition: 400V, 10A, 25Ohm, 15V
- ReverseRecoveryTime(trr): -
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Through Hole
- Package/Case: TO-220-3
- SGP10N60AXKSA1 Infineon, IGBT 600V 20A 92W TO220-3, Discrete Semiconductor Products~Transistors - IGBTs - Single
SGP10N60AXKSA1, Infineon authentic parts in stock from Infineon authorized distributors, order today, can ship immediately.
