SGB15N60HSATMA1 Images
- Manufacturer: Infineon Technologies
- Category: Discrete Semiconductor Products~Transistors - IGBTs - Single Package/Case: TO-263-3, D²Pak (2 Leads + Tab), TO-263AB
- Description: IGBT 600V 27A 138W TO263-3
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
SGB15N60HSATMA1 Specifications:
- MfrPart.: SGB15N60HSATMA1
- Mfr: Infineon Technologies
- Description: IGBT 600V 27A 138W TO263-3
- Product Category: Discrete Semiconductor Products~Transistors - IGBTs - Single
- Package: Tape & Reel (TR)
- Series: -
- PartStatus: Obsolete
- IGBTType: NPT
- Voltage-CollectorEmitterBreakdown(Max): 600 V
- Current-Collector(Ic)(Max): 27 A
- Current-CollectorPulsed(Icm): 60 A
- Vce(on)(Max)@VgeIc: 3.15V @ 15V, 15A
- Power-Max: 138 W
- SwitchingEnergy: 530µJ
- InputType: Standard
- GateCharge: 80 nC
- Td(on/off)@25°C: 13ns/209ns
- TestCondition: 400V, 15A, 23Ohm, 15V
- ReverseRecoveryTime(trr): -
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Surface Mount
- Package/Case: TO-263-3, D²Pak (2 Leads + Tab), TO-263AB
- SGB15N60HSATMA1 Infineon, IGBT 600V 27A 138W TO263-3, Discrete Semiconductor Products~Transistors - IGBTs - Single
SGB15N60HSATMA1, Infineon authentic parts in stock from Infineon authorized distributors, order today, can ship immediately.
