SGB07N120ATMA1 Images
- Manufacturer: Infineon Technologies
- Category: Discrete Semiconductor Products~Transistors - IGBTs - Single Package/Case: TO-263-3, D²Pak (2 Leads + Tab), TO-263AB
- Description: IGBT 1200V 16.5A 125W TO263-3-2
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
SGB07N120ATMA1 Specifications:
- MfrPart.: SGB07N120ATMA1
- Mfr: Infineon Technologies
- Description: IGBT 1200V 16.5A 125W TO263-3-2
- Product Category: Discrete Semiconductor Products~Transistors - IGBTs - Single
- Package: Tape & Reel (TR)
- Series: -
- PartStatus: Last Time Buy
- IGBTType: NPT
- Voltage-CollectorEmitterBreakdown(Max): 1200 V
- Current-Collector(Ic)(Max): 16.5 A
- Current-CollectorPulsed(Icm): 27 A
- Vce(on)(Max)@VgeIc: 3.6V @ 15V, 8A
- Power-Max: 125 W
- SwitchingEnergy: 1mJ
- InputType: Standard
- GateCharge: 70 nC
- Td(on/off)@25°C: 27ns/440ns
- TestCondition: 800V, 8A, 47Ohm, 15V
- ReverseRecoveryTime(trr): -
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Surface Mount
- Package/Case: TO-263-3, D²Pak (2 Leads + Tab), TO-263AB
- SGB07N120ATMA1 Infineon, IGBT 1200V 16.5A 125W TO263-3-2, Discrete Semiconductor Products~Transistors - IGBTs - Single
