IRSM505-084DA Images
- Manufacturer: Infineon Technologies
- Category: Integrated Circuits (ICs)~PMIC - Full, Half-Bridge Drivers Package/Case: 23-DIP Module
- Description: INTELLIGENT POWER MODULE (IPM)
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
IRSM505-084DA Specifications:
- MfrPart.: IRSM505-084DA
- Mfr: Infineon Technologies
- Description: INTELLIGENT POWER MODULE (IPM)
- Product Category: Integrated Circuits (ICs)~PMIC - Full, Half-Bridge Drivers
- Package: Bulk
- Series: µIPM™-DIP
- PartStatus: Active
- OutputConfiguration: Half Bridge (3)
- Applications: AC Motors
- Interface: Logic
- LoadType: Inductive
- Technology: UMOS
- RdsOn(Typ): 340mOhm
- Current-Output/Channel: 4.6A
- Current-PeakOutput: 15A
- Voltage-Supply: 13.5V ~ 16.5V
- Voltage-Load: 200V (Max)
- OperatingTemperature: -40°C ~ 150°C (TJ)
- Features: Bootstrap Circuit
- FaultProtection: UVLO
- MountingType: Through Hole
- Package/Case: 23-DIP Module
- IRSM505-084DA Infineon, INTELLIGENT POWER MODULE (IPM), Integrated Circuits (ICs)~PMIC - Full, Half-Bridge Drivers
