IRLR8503 Images
- Manufacturer: Infineon Technologies
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: D-Pak
- Description: MOSFET N-CH 30V 44A DPAK
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
IRLR8503 Specifications:
- MfrPart.: IRLR8503
- Mfr: Infineon Technologies
- Description: MOSFET N-CH 30V 44A DPAK
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tube
- Series: HEXFET®
- PartStatus: Obsolete
- FETType: N-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 30 V
- Current-ContinuousDrain(Id)@25°C: 44A (Tc)
- DriveVoltage(MaxRdsOnMinRdsOn): 4.5V, 10V
- RdsOn(Max)@IdVgs: 16mOhm @ 15A, 10V
- Vgs(th)(Max)@Id: 3V @ 250µA
- GateCharge(Qg)(Max)@Vgs: 20 nC @ 5 V
- Vgs(Max): ±20V
- InputCapacitance(Ciss)(Max)@Vds: 1650 pF @ 25 V
- FETFeature: -
- PowerDissipation(Max): 62W (Tc)
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Surface Mount
- SupplierDevicePackage: D-Pak
- IRLR8503 Infineon, MOSFET N-CH 30V 44A DPAK, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
