IRLR3717TRLPBF Images
- Manufacturer: Infineon Technologies
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: D-Pak
- Description: MOSFET N-CH 20V 120A DPAK
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
IRLR3717TRLPBF Specifications:
- MfrPart.: IRLR3717TRLPBF
- Mfr: Infineon Technologies
- Description: MOSFET N-CH 20V 120A DPAK
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tape & Reel (TR)
- Series: HEXFET®
- PartStatus: Obsolete
- FETType: N-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 20 V
- Current-ContinuousDrain(Id)@25°C: 120A (Tc)
- DriveVoltage(MaxRdsOnMinRdsOn): 4.5V, 10V
- RdsOn(Max)@IdVgs: 4mOhm @ 15A, 10V
- Vgs(th)(Max)@Id: 2.45V @ 250µA
- GateCharge(Qg)(Max)@Vgs: 31 nC @ 4.5 V
- Vgs(Max): ±20V
- InputCapacitance(Ciss)(Max)@Vds: 2830 pF @ 10 V
- FETFeature: -
- PowerDissipation(Max): 89W (Tc)
- OperatingTemperature: -55°C ~ 175°C (TJ)
- MountingType: Surface Mount
- SupplierDevicePackage: D-Pak
- IRLR3717TRLPBF Infineon, MOSFET N-CH 20V 120A DPAK, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
IRLR3717TRLPBF, Infineon authentic parts in stock from Infineon authorized distributors, order today, can ship immediately.
