IRLR3103 Images
- Manufacturer: Infineon Technologies
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: D-Pak
- Description: MOSFET N-CH 30V 55A DPAK
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
IRLR3103 Specifications:
- MfrPart.: IRLR3103
- Mfr: Infineon Technologies
- Description: MOSFET N-CH 30V 55A DPAK
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tube
- Series: HEXFET®
- PartStatus: Obsolete
- FETType: N-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 30 V
- Current-ContinuousDrain(Id)@25°C: 55A (Tc)
- DriveVoltage(MaxRdsOnMinRdsOn): 4.5V, 10V
- RdsOn(Max)@IdVgs: 19mOhm @ 33A, 10V
- Vgs(th)(Max)@Id: 1V @ 250µA
- GateCharge(Qg)(Max)@Vgs: 50 nC @ 4.5 V
- Vgs(Max): ±16V
- InputCapacitance(Ciss)(Max)@Vds: 1600 pF @ 25 V
- FETFeature: -
- PowerDissipation(Max): 107W (Tc)
- OperatingTemperature: -55°C ~ 175°C (TJ)
- MountingType: Surface Mount
- SupplierDevicePackage: D-Pak
- IRLR3103 Infineon, MOSFET N-CH 30V 55A DPAK, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
IRLR3103, Infineon authentic parts in stock from Infineon authorized distributors, order today, can ship immediately.
