IRLL014NPBF Images
- Manufacturer: Infineon Technologies
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: SOT-223
- Description: MOSFET N-CH 55V 2A SOT223
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
IRLL014NPBF Specifications:
- MfrPart.: IRLL014NPBF
- Mfr: Infineon Technologies
- Description: MOSFET N-CH 55V 2A SOT223
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tube
- Series: HEXFET®
- PartStatus: Discontinued at
- FETType: N-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 55 V
- Current-ContinuousDrain(Id)@25°C: 2A (Ta)
- DriveVoltage(MaxRdsOnMinRdsOn): 4V, 10V
- RdsOn(Max)@IdVgs: 140mOhm @ 2A, 10V
- Vgs(th)(Max)@Id: 2V @ 250µA
- GateCharge(Qg)(Max)@Vgs: 14 nC @ 10 V
- Vgs(Max): ±16V
- InputCapacitance(Ciss)(Max)@Vds: 230 pF @ 25 V
- FETFeature: -
- PowerDissipation(Max): 1W (Ta)
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Surface Mount
- SupplierDevicePackage: SOT-223
- IRLL014NPBF Infineon, MOSFET N-CH 55V 2A SOT223, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
IRLL014NPBF, Infineon authentic parts in stock from Infineon authorized distributors, order today, can ship immediately.
