IRLI3803PBF Images
- Manufacturer: Infineon Technologies
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: TO-220AB Full-Pak
- Description: MOSFET N-CH 30V 76A TO220AB FP
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
IRLI3803PBF Specifications:
- MfrPart.: IRLI3803PBF
- Mfr: Infineon Technologies
- Description: MOSFET N-CH 30V 76A TO220AB FP
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tube
- Series: HEXFET®
- PartStatus: Obsolete
- FETType: N-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 30 V
- Current-ContinuousDrain(Id)@25°C: 76A (Tc)
- DriveVoltage(MaxRdsOnMinRdsOn): 4.5V, 10V
- RdsOn(Max)@IdVgs: 6mOhm @ 40A, 10V
- Vgs(th)(Max)@Id: 1V @ 250µA
- GateCharge(Qg)(Max)@Vgs: 140 nC @ 4.5 V
- Vgs(Max): ±16V
- InputCapacitance(Ciss)(Max)@Vds: 5000 pF @ 25 V
- FETFeature: -
- PowerDissipation(Max): 63W (Tc)
- OperatingTemperature: -55°C ~ 175°C (TJ)
- MountingType: Through Hole
- SupplierDevicePackage: TO-220AB Full-Pak
- IRLI3803PBF Infineon, MOSFET N-CH 30V 76A TO220AB FP, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
