IRLHS6242TRPBF Images
- Manufacturer: Infineon Technologies
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: 6-PQFN (2x2)
- Description: MOSFET N-CH 20V 10A/12A 6PQFN
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
IRLHS6242TRPBF Specifications:
- MfrPart.: IRLHS6242TRPBF
- Mfr: Infineon Technologies
- Description: MOSFET N-CH 20V 10A/12A 6PQFN
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tape & Reel (TR),Cut Tape (CT)
- Series: HEXFET®
- PartStatus: Active
- FETType: N-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 20 V
- Current-ContinuousDrain(Id)@25°C: 10A (Ta), 12A (Tc)
- DriveVoltage(MaxRdsOnMinRdsOn): 2.5V, 4.5V
- RdsOn(Max)@IdVgs: 11.7mOhm @ 8.5A, 4.5V
- Vgs(th)(Max)@Id: 1.1V @ 10µA
- GateCharge(Qg)(Max)@Vgs: 14 nC @ 4.5 V
- Vgs(Max): ±12V
- InputCapacitance(Ciss)(Max)@Vds: 1110 pF @ 10 V
- FETFeature: -
- PowerDissipation(Max): 1.98W (Ta), 9.6W (Tc)
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Surface Mount
- SupplierDevicePackage: 6-PQFN (2x2)
- IRLHS6242TRPBF Infineon, MOSFET N-CH 20V 10A/12A 6PQFN, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
IRLHS6242TRPBF, Infineon authentic parts in stock from Infineon authorized distributors, order today, can ship immediately.
