IRL3714ZL Images
- Manufacturer: Infineon Technologies
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: TO-262
- Description: MOSFET N-CH 20V 36A TO262
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
IRL3714ZL Specifications:
- MfrPart.: IRL3714ZL
- Mfr: Infineon Technologies
- Description: MOSFET N-CH 20V 36A TO262
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tube
- Series: HEXFET®
- PartStatus: Obsolete
- FETType: N-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 20 V
- Current-ContinuousDrain(Id)@25°C: 36A (Tc)
- DriveVoltage(MaxRdsOnMinRdsOn): 4.5V, 10V
- RdsOn(Max)@IdVgs: 16mOhm @ 15A, 10V
- Vgs(th)(Max)@Id: 2.55V @ 250µA
- GateCharge(Qg)(Max)@Vgs: 7.2 nC @ 4.5 V
- Vgs(Max): ±20V
- InputCapacitance(Ciss)(Max)@Vds: 550 pF @ 10 V
- FETFeature: -
- PowerDissipation(Max): 35W (Tc)
- OperatingTemperature: -55°C ~ 175°C (TJ)
- MountingType: Through Hole
- SupplierDevicePackage: TO-262
- IRL3714ZL Infineon, MOSFET N-CH 20V 36A TO262, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
