IRL2203NPBF Images
- Manufacturer: Infineon Technologies
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: TO-220AB
- Description: HEXFET POWER MOSFET
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
IRL2203NPBF Specifications:
- MfrPart.: IRL2203NPBF
- Mfr: International Rectifier (Now part of Infineon Technologies)
- Description: HEXFET POWER MOSFET
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Bulk
- Series: HEXFET®
- PartStatus: Active
- FETType: N-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 30 V
- Current-ContinuousDrain(Id)@25°C: 116A (Tc)
- DriveVoltage(MaxRdsOnMinRdsOn): 4.5V, 10V
- RdsOn(Max)@IdVgs: 7mOhm @ 60A, 10V
- Vgs(th)(Max)@Id: 1V @ 250µA
- GateCharge(Qg)(Max)@Vgs: 60 nC @ 4.5 V
- Vgs(Max): ±16V
- InputCapacitance(Ciss)(Max)@Vds: 3.29 pF @ 25 V
- FETFeature: -
- PowerDissipation(Max): 180W (Tc)
- OperatingTemperature: -55°C ~ 175°C (TJ)
- MountingType: Through Hole
- SupplierDevicePackage: TO-220AB
- IRL2203NPBF Infineon, HEXFET POWER MOSFET, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
IRL2203NPBF, Infineon authentic parts in stock from Infineon authorized distributors, order today, can ship immediately.
