IRGPS40B120UDP Images
- Manufacturer: Infineon Technologies
- Category: Discrete Semiconductor Products~Transistors - IGBTs - Single Package/Case: TO-274AA
- Description: IGBT WITH RECOVERY DIODE
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
IRGPS40B120UDP Specifications:
- MfrPart.: IRGPS40B120UDP
- Mfr: Infineon Technologies
- Description: IGBT WITH RECOVERY DIODE
- Product Category: Discrete Semiconductor Products~Transistors - IGBTs - Single
- Package: Bag
- Series: -
- PartStatus: Obsolete
- IGBTType: NPT
- Voltage-CollectorEmitterBreakdown(Max): 1.2 kV
- Current-Collector(Ic)(Max): 80 A
- Current-CollectorPulsed(Icm): 160 A
- Vce(on)(Max)@VgeIc: 3.7V @ 15V, 50A
- Power-Max: 595 W
- SwitchingEnergy: 1.4mJ (on), 1.65mJ (off)
- InputType: Standard
- GateCharge: 340 nC
- Td(on/off)@25°C: -
- TestCondition: 600V, 40A, 4.7Ohm, 15V
- ReverseRecoveryTime(trr): 180 ns
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Through Hole
- Package/Case: TO-274AA
- IRGPS40B120UDP Infineon, IGBT WITH RECOVERY DIODE, Discrete Semiconductor Products~Transistors - IGBTs - Single
IRGPS40B120UDP, Infineon authentic parts in stock from Infineon authorized distributors, order today, can ship immediately.
