IRGP20B120UD-EP Images
- Manufacturer: Infineon Technologies
- Category: Discrete Semiconductor Products~Transistors - IGBTs - Single Package/Case: TO-247-3
- Description: IGBT 1200V 40A 300W TO247AD
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
IRGP20B120UD-EP Specifications:
- MfrPart.: IRGP20B120UD-EP
- Mfr: Infineon Technologies
- Description: IGBT 1200V 40A 300W TO247AD
- Product Category: Discrete Semiconductor Products~Transistors - IGBTs - Single
- Package: Bulk
- Series: -
- PartStatus: Obsolete
- IGBTType: NPT
- Voltage-CollectorEmitterBreakdown(Max): 1200 V
- Current-Collector(Ic)(Max): 40 A
- Current-CollectorPulsed(Icm): 120 A
- Vce(on)(Max)@VgeIc: 4.85V @ 15V, 40A
- Power-Max: 300 W
- SwitchingEnergy: 850µJ (on), 425µJ (off)
- InputType: Standard
- GateCharge: 169 nC
- Td(on/off)@25°C: -
- TestCondition: 600V, 20A, 5Ohm, 15V
- ReverseRecoveryTime(trr): 300 ns
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Through Hole
- Package/Case: TO-247-3
- IRGP20B120UD-EP Infineon, IGBT 1200V 40A 300W TO247AD, Discrete Semiconductor Products~Transistors - IGBTs - Single
IRGP20B120UD-EP, Infineon authentic parts in stock from Infineon authorized distributors, order today, can ship immediately.
