IRGB5B120KDPBF Images
- Manufacturer: Infineon Technologies
- Category: Discrete Semiconductor Products~Transistors - IGBTs - Single Package/Case: TO-220-3
- Description: IGBT 1200V 12A 89W TO220AB
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
IRGB5B120KDPBF Specifications:
- MfrPart.: IRGB5B120KDPBF
- Mfr: Infineon Technologies
- Description: IGBT 1200V 12A 89W TO220AB
- Product Category: Discrete Semiconductor Products~Transistors - IGBTs - Single
- Package: Tube
- Series: -
- PartStatus: Obsolete
- IGBTType: NPT
- Voltage-CollectorEmitterBreakdown(Max): 1200 V
- Current-Collector(Ic)(Max): 12 A
- Current-CollectorPulsed(Icm): 24 A
- Vce(on)(Max)@VgeIc: 3V @ 15V, 6A
- Power-Max: 89 W
- SwitchingEnergy: 390µJ (on), 330µJ (off)
- InputType: Standard
- GateCharge: 25 nC
- Td(on/off)@25°C: 22ns/100ns
- TestCondition: 600V, 6A, 50Ohm, 15V
- ReverseRecoveryTime(trr): 160 ns
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Through Hole
- Package/Case: TO-220-3
- IRGB5B120KDPBF Infineon, IGBT 1200V 12A 89W TO220AB, Discrete Semiconductor Products~Transistors - IGBTs - Single
IRGB5B120KDPBF, Infineon authentic parts in stock from Infineon authorized distributors, order today, can ship immediately.
