IRGB20B60PD1PBF Images
- Manufacturer: Infineon Technologies
- Category: Discrete Semiconductor Products~Transistors - IGBTs - Single Package/Case: TO-220-3
- Description: IGBT 600V 40A 215W TO220AB
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
IRGB20B60PD1PBF Specifications:
- MfrPart.: IRGB20B60PD1PBF
- Mfr: Infineon Technologies
- Description: IGBT 600V 40A 215W TO220AB
- Product Category: Discrete Semiconductor Products~Transistors - IGBTs - Single
- Package: Tube
- Series: -
- PartStatus: Obsolete
- IGBTType: NPT
- Voltage-CollectorEmitterBreakdown(Max): 600 V
- Current-Collector(Ic)(Max): 40 A
- Current-CollectorPulsed(Icm): 80 A
- Vce(on)(Max)@VgeIc: 2.8V @ 15V, 20A
- Power-Max: 215 W
- SwitchingEnergy: 95µJ (on), 100µJ (off)
- InputType: Standard
- GateCharge: 68 nC
- Td(on/off)@25°C: 20ns/115ns
- TestCondition: 390V, 13A, 10Ohm, 15V
- ReverseRecoveryTime(trr): 28 ns
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Through Hole
- Package/Case: TO-220-3
- IRGB20B60PD1PBF Infineon, IGBT 600V 40A 215W TO220AB, Discrete Semiconductor Products~Transistors - IGBTs - Single
IRGB20B60PD1PBF, Infineon authentic parts in stock from Infineon authorized distributors, order today, can ship immediately.
