IRGB10B60KDPBF Images
- Manufacturer: Infineon Technologies
- Category: Discrete Semiconductor Products~Transistors - IGBTs - Single Package/Case: TO-220-3
- Description: IGBT, 22A I(C), 600V V(BR)CES, N
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
IRGB10B60KDPBF Specifications:
- MfrPart.: IRGB10B60KDPBF
- Mfr: International Rectifier (Now part of Infineon Technologies)
- Description: IGBT, 22A I(C), 600V V(BR)CES, N
- Product Category: Discrete Semiconductor Products~Transistors - IGBTs - Single
- Package: Bulk
- Series: -
- PartStatus: Active
- IGBTType: NPT
- Voltage-CollectorEmitterBreakdown(Max): 600 V
- Current-Collector(Ic)(Max): 22 A
- Current-CollectorPulsed(Icm): 44 A
- Vce(on)(Max)@VgeIc: 2.2V @ 15V, 10A
- Power-Max: 156 W
- SwitchingEnergy: 140µJ (on), 250µJ (off)
- InputType: Standard
- GateCharge: 38 nC
- Td(on/off)@25°C: 30ns/230ns
- TestCondition: 400V, 10A, 47Ohm, 15V
- ReverseRecoveryTime(trr): 90 ns
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Through Hole
- Package/Case: TO-220-3
- IRGB10B60KDPBF Infineon, IGBT, 22A I(C), 600V V(BR)CES, N, Discrete Semiconductor Products~Transistors - IGBTs - Single
