IRG8P40N120KDPBF Images
- Manufacturer: Infineon Technologies
- Category: Discrete Semiconductor Products~Transistors - IGBTs - Single Package/Case: TO-247-3
- Description: IRG8P40N120 - DISCRETE IGBT WITH
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
IRG8P40N120KDPBF Specifications:
- MfrPart.: IRG8P40N120KDPBF
- Mfr: International Rectifier (Now part of Infineon Technologies)
- Description: IRG8P40N120 - DISCRETE IGBT WITH
- Product Category: Discrete Semiconductor Products~Transistors - IGBTs - Single
- Package: Bulk
- Series: -
- PartStatus: Obsolete
- IGBTType: -
- Voltage-CollectorEmitterBreakdown(Max): 1.2 kV
- Current-Collector(Ic)(Max): 60 A
- Current-CollectorPulsed(Icm): 75 A
- Vce(on)(Max)@VgeIc: 2V @ 15V, 25A
- Power-Max: 305 W
- SwitchingEnergy: 1.6mJ (on), 1.8mJ (off)
- InputType: Standard
- GateCharge: 240 nC
- Td(on/off)@25°C: 40ns/245ns
- TestCondition: 600V, 25A, 10Ohm, 15V
- ReverseRecoveryTime(trr): 80 ns
- OperatingTemperature: -40°C ~ 150°C (TJ)
- MountingType: Through Hole
- Package/Case: TO-247-3
- IRG8P40N120KDPBF Infineon, IRG8P40N120 - DISCRETE IGBT WITH, Discrete Semiconductor Products~Transistors - IGBTs - Single
IRG8P40N120KDPBF, Infineon authentic parts in stock from Infineon authorized distributors, order today, can ship immediately.
