IRG7PH42UDPBF Images
- Manufacturer: Infineon Technologies
- Category: Discrete Semiconductor Products~Transistors - IGBTs - Single Package/Case: TO-247-3
- Description: IGBT TRENCH 1200V 85A TO247AC
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
IRG7PH42UDPBF Specifications:
- MfrPart.: IRG7PH42UDPBF
- Mfr: Infineon Technologies
- Description: IGBT TRENCH 1200V 85A TO247AC
- Product Category: Discrete Semiconductor Products~Transistors - IGBTs - Single
- Package: Tube
- Series: -
- PartStatus: Obsolete
- IGBTType: Trench
- Voltage-CollectorEmitterBreakdown(Max): 1200 V
- Current-Collector(Ic)(Max): 85 A
- Current-CollectorPulsed(Icm): 90 A
- Vce(on)(Max)@VgeIc: 2V @ 15V, 30A
- Power-Max: 320 W
- SwitchingEnergy: 2.11mJ (on), 1.18mJ (off)
- InputType: Standard
- GateCharge: 157 nC
- Td(on/off)@25°C: 25ns/229ns
- TestCondition: 600V, 30A, 10Ohm, 15V
- ReverseRecoveryTime(trr): 153 ns
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Through Hole
- Package/Case: TO-247-3
- IRG7PH42UDPBF Infineon, IGBT TRENCH 1200V 85A TO247AC, Discrete Semiconductor Products~Transistors - IGBTs - Single
