IRG7PH42UD2PBF Images
- Manufacturer: Infineon Technologies
- Category: Discrete Semiconductor Products~Transistors - IGBTs - Single Package/Case: TO-247-3
- Description: IGBT 1200V 60A 321W TO247AC
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
IRG7PH42UD2PBF Specifications:
- MfrPart.: IRG7PH42UD2PBF
- Mfr: Infineon Technologies
- Description: IGBT 1200V 60A 321W TO247AC
- Product Category: Discrete Semiconductor Products~Transistors - IGBTs - Single
- Package: Tube
- Series: -
- PartStatus: Obsolete
- IGBTType: Trench
- Voltage-CollectorEmitterBreakdown(Max): 1200 V
- Current-Collector(Ic)(Max): 60 A
- Current-CollectorPulsed(Icm): 90 A
- Vce(on)(Max)@VgeIc: 2.02V @ 15V, 30A
- Power-Max: 321 W
- SwitchingEnergy: 1.32mJ (off)
- InputType: Standard
- GateCharge: 234 nC
- Td(on/off)@25°C: -/233ns
- TestCondition: 600V, 30A, 10Ohm, 15V
- ReverseRecoveryTime(trr): -
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Through Hole
- Package/Case: TO-247-3
- IRG7PH42UD2PBF Infineon, IGBT 1200V 60A 321W TO247AC, Discrete Semiconductor Products~Transistors - IGBTs - Single
IRG7PH42UD2PBF, Infineon authentic parts in stock from Infineon authorized distributors, order today, can ship immediately.
