IRG4PSH71KDPBF Images
- Manufacturer: Infineon Technologies
- Category: Discrete Semiconductor Products~Transistors - IGBTs - Single Package/Case: TO-274AA
- Description: IRG4PSH71 - DISCRETE IGBT WITH A
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
IRG4PSH71KDPBF Specifications:
- MfrPart.: IRG4PSH71KDPBF
- Mfr: International Rectifier (Now part of Infineon Technologies)
- Description: IRG4PSH71 - DISCRETE IGBT WITH A
- Product Category: Discrete Semiconductor Products~Transistors - IGBTs - Single
- Package: Bulk
- Series: -
- PartStatus: Obsolete
- IGBTType: -
- Voltage-CollectorEmitterBreakdown(Max): 1.2 kV
- Current-Collector(Ic)(Max): 78 A
- Current-CollectorPulsed(Icm): 156 A
- Vce(on)(Max)@VgeIc: 3.9V @ 15V, 42A
- Power-Max: 350 W
- SwitchingEnergy: 5.68mJ (on), 3.23mJ (off)
- InputType: Standard
- GateCharge: 410 nC
- Td(on/off)@25°C: 67ns/230ns
- TestCondition: 800V, 42A, 5Ohm, 15V
- ReverseRecoveryTime(trr): 107 ns
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Through Hole
- Package/Case: TO-274AA
- IRG4PSH71KDPBF Infineon, IRG4PSH71 - DISCRETE IGBT WITH A, Discrete Semiconductor Products~Transistors - IGBTs - Single
IRG4PSH71KDPBF, Infineon authentic parts in stock from Infineon authorized distributors, order today, can ship immediately.
