IRFR3504ZTRL Infineon MOSFET N-CH 40V 42A DPAK
IRFR3504ZTRL Images
IRFR3504ZTRL Images
  • Manufacturer: Infineon Technologies
  • Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: D-Pak
  • Description: MOSFET N-CH 40V 42A DPAK
  • COMPETITIVE PRICE and DELIVERY TIME
  • Order with confidence, there are no lead times for in-stock products.
Quickly Quote for You to Meet Your Target Price, Support Small Order Quantity with Fast Quick Delivery.
Download Datasheet (PDF)
IRFR3504ZTRL Datasheet
ELECTRONIC COMPONENTS, CHOOSE NHE ELECTRONICS
IRFR3504ZTRL Specifications:
  • MfrPart.: IRFR3504ZTRL
  • Mfr: Infineon Technologies
  • Description: MOSFET N-CH 40V 42A DPAK
  • Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
  • Package: Tape & Reel (TR)
  • Series: HEXFET®
  • PartStatus: Obsolete
  • FETType: N-Channel
  • Technology: MOSFET (Metal Oxide)
  • DraintoSourceVoltage(Vdss): 40 V
  • Current-ContinuousDrain(Id)@25°C: 42A (Tc)
  • DriveVoltage(MaxRdsOnMinRdsOn): 10V
  • RdsOn(Max)@IdVgs: 9mOhm @ 42A, 10V
  • Vgs(th)(Max)@Id: 4V @ 50µA
  • GateCharge(Qg)(Max)@Vgs: 45 nC @ 10 V
  • Vgs(Max): ±20V
  • InputCapacitance(Ciss)(Max)@Vds: 1510 pF @ 25 V
  • FETFeature: -
  • PowerDissipation(Max): 90W (Tc)
  • OperatingTemperature: -55°C ~ 175°C (TJ)
  • MountingType: Surface Mount
  • SupplierDevicePackage: D-Pak
  • IRFR3504ZTRL Infineon, MOSFET N-CH 40V 42A DPAK, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
IRFR3504ZTRL, Infineon authentic parts in stock from Infineon authorized distributors, order today, can ship immediately.
