IRFIZ48N Images
- Manufacturer: Infineon Technologies
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: PG-TO220-FP
- Description: MOSFET N-CH 55V 36A TO220AB FP
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
IRFIZ48N Specifications:
- MfrPart.: IRFIZ48N
- Mfr: Infineon Technologies
- Description: MOSFET N-CH 55V 36A TO220AB FP
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tube
- Series: HEXFET®
- PartStatus: Obsolete
- FETType: N-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 55 V
- Current-ContinuousDrain(Id)@25°C: 36A (Tc)
- DriveVoltage(MaxRdsOnMinRdsOn): 10V
- RdsOn(Max)@IdVgs: 16mOhm @ 22A, 10V
- Vgs(th)(Max)@Id: 4V @ 250µA
- GateCharge(Qg)(Max)@Vgs: 89 nC @ 10 V
- Vgs(Max): ±20V
- InputCapacitance(Ciss)(Max)@Vds: 1900 pF @ 25 V
- FETFeature: -
- PowerDissipation(Max): 42W (Tc)
- OperatingTemperature: -55°C ~ 175°C (TJ)
- MountingType: Through Hole
- SupplierDevicePackage: PG-TO220-FP
- IRFIZ48N Infineon, MOSFET N-CH 55V 36A TO220AB FP, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
IRFIZ48N, Infineon authentic parts in stock from Infineon authorized distributors, order today, can ship immediately.
