IRFH5220TRPBF Images
- Manufacturer: Infineon Technologies
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: PQFN (5x6)
- Description: MOSFET N-CH 200V 3.8A/20A PQFN
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
IRFH5220TRPBF Specifications:
- MfrPart.: IRFH5220TRPBF
- Mfr: Infineon Technologies
- Description: MOSFET N-CH 200V 3.8A/20A PQFN
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tape & Reel (TR)
- Series: HEXFET®
- PartStatus: Obsolete
- FETType: N-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 200 V
- Current-ContinuousDrain(Id)@25°C: 3.8A (Ta), 20A (Tc)
- DriveVoltage(MaxRdsOnMinRdsOn): 10V
- RdsOn(Max)@IdVgs: 99.9mOhm @ 5.8A, 10V
- Vgs(th)(Max)@Id: 5V @ 100µA
- GateCharge(Qg)(Max)@Vgs: 30 nC @ 10 V
- Vgs(Max): ±20V
- InputCapacitance(Ciss)(Max)@Vds: 1380 pF @ 50 V
- FETFeature: -
- PowerDissipation(Max): 3.6W (Ta), 8.3W (Tc)
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Surface Mount
- SupplierDevicePackage: PQFN (5x6)
- IRFH5220TRPBF Infineon, MOSFET N-CH 200V 3.8A/20A PQFN, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
IRFH5220TRPBF, Infineon authentic parts in stock from Infineon authorized distributors, order today, can ship immediately.
