IRF9520NPBF Images
- Manufacturer: Infineon Technologies
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: TO-220AB
- Description: MOSFET P-CH 100V 6.8A TO220AB
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
IRF9520NPBF Specifications:
- MfrPart.: IRF9520NPBF
- Mfr: Infineon Technologies
- Description: MOSFET P-CH 100V 6.8A TO220AB
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tube
- Series: HEXFET®
- PartStatus: Active
- FETType: P-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 100 V
- Current-ContinuousDrain(Id)@25°C: 6.8A (Tc)
- DriveVoltage(MaxRdsOnMinRdsOn): -
- RdsOn(Max)@IdVgs: 480mOhm @ 4A, 10V
- Vgs(th)(Max)@Id: 4V @ 250µA
- GateCharge(Qg)(Max)@Vgs: 27 nC @ 10 V
- Vgs(Max): -
- InputCapacitance(Ciss)(Max)@Vds: 350 pF @ 25 V
- FETFeature: -
- PowerDissipation(Max): -
- OperatingTemperature: -
- MountingType: Through Hole
- SupplierDevicePackage: TO-220AB
- IRF9520NPBF Infineon, MOSFET P-CH 100V 6.8A TO220AB, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
IRF9520NPBF, Infineon authentic parts in stock from Infineon authorized distributors, order today, can ship immediately.
