IRF7809AVTRPBF-1 Images
- Manufacturer: Infineon Technologies
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: 8-SOIC
- Description: MOSFET N-CH 30V 13.3A 8SO
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
IRF7809AVTRPBF-1 Specifications:
- MfrPart.: IRF7809AVTRPBF-1
- Mfr: Infineon Technologies
- Description: MOSFET N-CH 30V 13.3A 8SO
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tape & Reel (TR)
- Series: HEXFET®
- PartStatus: Obsolete
- FETType: N-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 30 V
- Current-ContinuousDrain(Id)@25°C: 13.3A (Ta)
- DriveVoltage(MaxRdsOnMinRdsOn): 4.5V
- RdsOn(Max)@IdVgs: 9mOhm @ 15A, 4.5V
- Vgs(th)(Max)@Id: 1V @ 250µA
- GateCharge(Qg)(Max)@Vgs: 62 nC @ 5 V
- Vgs(Max): ±12V
- InputCapacitance(Ciss)(Max)@Vds: 3780 pF @ 16 V
- FETFeature: -
- PowerDissipation(Max): 2.5W (Ta)
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Surface Mount
- SupplierDevicePackage: 8-SOIC
- IRF7809AVTRPBF-1 Infineon, MOSFET N-CH 30V 13.3A 8SO, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
IRF7809AVTRPBF-1, Infineon authentic parts in stock from Infineon authorized distributors, order today, can ship immediately.
