IRF7769L2TRPBF Images
- Manufacturer: Infineon Technologies
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: DIRECTFET L8
- Description: IRF7769 - 12V-300V N-CHANNEL POW
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
IRF7769L2TRPBF Specifications:
- MfrPart.: IRF7769L2TRPBF
- Mfr: International Rectifier (Now part of Infineon Technologies)
- Description: IRF7769 - 12V-300V N-CHANNEL POW
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Bulk
- Series: HEXFET®
- PartStatus: Active
- FETType: N-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 100 V
- Current-ContinuousDrain(Id)@25°C: 375A (Tc)
- DriveVoltage(MaxRdsOnMinRdsOn): 10V
- RdsOn(Max)@IdVgs: 3.5mOhm @ 74A, 10V
- Vgs(th)(Max)@Id: 4V @ 250µA
- GateCharge(Qg)(Max)@Vgs: 300 nC @ 10 V
- Vgs(Max): ±20V
- InputCapacitance(Ciss)(Max)@Vds: 11.56 pF @ 25 V
- FETFeature: -
- PowerDissipation(Max): 3.3W (Ta), 125W (Tc)
- OperatingTemperature: -55°C ~ 175°C (TJ)
- MountingType: Surface Mount
- SupplierDevicePackage: DIRECTFET L8
- IRF7769L2TRPBF Infineon, IRF7769 - 12V-300V N-CHANNEL POW, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
IRF7769L2TRPBF, Infineon authentic parts in stock from Infineon authorized distributors, order today, can ship immediately.
