IRF7707 Images
- Manufacturer: Infineon Technologies
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: 8-TSSOP
- Description: MOSFET P-CH 20V 7A 8TSSOP
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
IRF7707 Specifications:
- MfrPart.: IRF7707
- Mfr: Infineon Technologies
- Description: MOSFET P-CH 20V 7A 8TSSOP
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tube
- Series: HEXFET®
- PartStatus: Obsolete
- FETType: P-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 20 V
- Current-ContinuousDrain(Id)@25°C: 7A (Ta)
- DriveVoltage(MaxRdsOnMinRdsOn): 2.5V, 4.5V
- RdsOn(Max)@IdVgs: 22mOhm @ 7A, 4.5V
- Vgs(th)(Max)@Id: 1.2V @ 250µA
- GateCharge(Qg)(Max)@Vgs: 47 nC @ 4.5 V
- Vgs(Max): ±12V
- InputCapacitance(Ciss)(Max)@Vds: 2361 pF @ 15 V
- FETFeature: -
- PowerDissipation(Max): 1.5W (Ta)
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Surface Mount
- SupplierDevicePackage: 8-TSSOP
- IRF7707 Infineon, MOSFET P-CH 20V 7A 8TSSOP, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
IRF7707, Infineon authentic parts in stock from Infineon authorized distributors, order today, can ship immediately.
