IRF6709S2TRPBF Infineon MOSFET N-CH 25V 12A DIRECTFET
IRF6709S2TRPBF Images
IRF6709S2TRPBF Images
  • Manufacturer: Infineon Technologies
  • Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: DirectFET™ Isometric S1
  • Description: MOSFET N-CH 25V 12A DIRECTFET
  • COMPETITIVE PRICE and DELIVERY TIME
  • Order with confidence, there are no lead times for in-stock products.
Quickly Quote for You to Meet Your Target Price, Support Small Order Quantity with Fast Quick Delivery.
Download Datasheet (PDF)
IRF6709S2TRPBF Datasheet
ELECTRONIC COMPONENTS, CHOOSE NHE ELECTRONICS
IRF6709S2TRPBF Specifications:
  • MfrPart.: IRF6709S2TRPBF
  • Mfr: Infineon Technologies
  • Description: MOSFET N-CH 25V 12A DIRECTFET
  • Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
  • Package: Tape & Reel (TR)
  • Series: HEXFET®
  • PartStatus: Obsolete
  • FETType: N-Channel
  • Technology: MOSFET (Metal Oxide)
  • DraintoSourceVoltage(Vdss): 25 V
  • Current-ContinuousDrain(Id)@25°C: 12A (Ta), 39A (Tc)
  • DriveVoltage(MaxRdsOnMinRdsOn): 4.5V, 10V
  • RdsOn(Max)@IdVgs: 7.8mOhm @ 12A, 10V
  • Vgs(th)(Max)@Id: 2.35V @ 25µA
  • GateCharge(Qg)(Max)@Vgs: 12 nC @ 4.5 V
  • Vgs(Max): ±20V
  • InputCapacitance(Ciss)(Max)@Vds: 1010 pF @ 13 V
  • FETFeature: -
  • PowerDissipation(Max): 1.8W (Ta), 21W (Tc)
  • OperatingTemperature: -55°C ~ 175°C (TJ)
  • MountingType: Surface Mount
  • SupplierDevicePackage: DirectFET™ Isometric S1
  • IRF6709S2TRPBF Infineon, MOSFET N-CH 25V 12A DIRECTFET, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
IRF6709S2TRPBF, Infineon authentic parts in stock from Infineon authorized distributors, order today, can ship immediately.
