IRF5804 Images
- Manufacturer: Infineon Technologies
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: Micro6™(TSOP-6)
- Description: MOSFET P-CH 40V 2.5A MICRO6
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
IRF5804 Specifications:
- MfrPart.: IRF5804
- Mfr: Infineon Technologies
- Description: MOSFET P-CH 40V 2.5A MICRO6
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tube
- Series: HEXFET®
- PartStatus: Obsolete
- FETType: P-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 40 V
- Current-ContinuousDrain(Id)@25°C: 2.5A (Ta)
- DriveVoltage(MaxRdsOnMinRdsOn): 4.5V, 10V
- RdsOn(Max)@IdVgs: 198mOhm @ 2.5A, 10V
- Vgs(th)(Max)@Id: 3V @ 250µA
- GateCharge(Qg)(Max)@Vgs: 21 nC @ 10 V
- Vgs(Max): ±20V
- InputCapacitance(Ciss)(Max)@Vds: 680 pF @ 25 V
- FETFeature: -
- PowerDissipation(Max): 2W (Ta)
- OperatingTemperature: -
- MountingType: Surface Mount
- SupplierDevicePackage: Micro6™(TSOP-6)
- IRF5804 Infineon, MOSFET P-CH 40V 2.5A MICRO6, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
IRF5804, Infineon authentic parts in stock from Infineon authorized distributors, order today, can ship immediately.
