IRF5803D2TRPBF Images
- Manufacturer: Infineon Technologies
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: 8-SO
- Description: MOSFET P-CH 40V 3.4A 8SO
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
IRF5803D2TRPBF Specifications:
- MfrPart.: IRF5803D2TRPBF
- Mfr: Infineon Technologies
- Description: MOSFET P-CH 40V 3.4A 8SO
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tape & Reel (TR),Cut Tape (CT)
- Series: FETKY™
- PartStatus: Obsolete
- FETType: P-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 40 V
- Current-ContinuousDrain(Id)@25°C: 3.4A (Ta)
- DriveVoltage(MaxRdsOnMinRdsOn): 4.5V, 10V
- RdsOn(Max)@IdVgs: 112mOhm @ 3.4A, 10V
- Vgs(th)(Max)@Id: 3V @ 250µA
- GateCharge(Qg)(Max)@Vgs: 37 nC @ 10 V
- Vgs(Max): ±20V
- InputCapacitance(Ciss)(Max)@Vds: 1110 pF @ 25 V
- FETFeature: Schottky Diode (Isolated)
- PowerDissipation(Max): 2W (Ta)
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Surface Mount
- SupplierDevicePackage: 8-SO
- IRF5803D2TRPBF Infineon, MOSFET P-CH 40V 3.4A 8SO, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
