IRF3709ZCS Images
- Manufacturer: Infineon Technologies
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: D2PAK
- Description: MOSFET N-CH 30V 87A D2PAK
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
IRF3709ZCS Specifications:
- MfrPart.: IRF3709ZCS
- Mfr: Infineon Technologies
- Description: MOSFET N-CH 30V 87A D2PAK
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tube
- Series: HEXFET®
- PartStatus: Obsolete
- FETType: N-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 30 V
- Current-ContinuousDrain(Id)@25°C: 87A (Tc)
- DriveVoltage(MaxRdsOnMinRdsOn): 4.5V, 10V
- RdsOn(Max)@IdVgs: 6.3mOhm @ 21A, 10V
- Vgs(th)(Max)@Id: 2.25V @ 250µA
- GateCharge(Qg)(Max)@Vgs: 26 nC @ 4.5 V
- Vgs(Max): ±20V
- InputCapacitance(Ciss)(Max)@Vds: 2130 pF @ 15 V
- FETFeature: -
- PowerDissipation(Max): 79W (Tc)
- OperatingTemperature: -55°C ~ 175°C (TJ)
- MountingType: Surface Mount
- SupplierDevicePackage: D2PAK
- IRF3709ZCS Infineon, MOSFET N-CH 30V 87A D2PAK, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
