IR21824 Images
- Manufacturer: Infineon Technologies
- Category: Integrated Circuits (ICs)~PMIC - Gate Drivers Package/Case: 14-DIP (0.300, 7.62mm)
- Description: IC GATE DRVR HALF-BRIDGE 14DIP
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
IR21824 Specifications:
- MfrPart.: IR21824
- Mfr: Infineon Technologies
- Description: IC GATE DRVR HALF-BRIDGE 14DIP
- Product Category: Integrated Circuits (ICs)~PMIC - Gate Drivers
- Package: Tube
- Series: -
- PartStatus: Obsolete
- DrivenConfiguration: Half-Bridge
- ChannelType: Independent
- NumberofDrivers: 2
- GateType: IGBT, N-Channel MOSFET
- Voltage-Supply: 10V ~ 20V
- LogicVoltage-VILVIH: 0.8V, 2.7V
- Current-PeakOutput(SourceSink): 1.9A, 2.3A
- InputType: Non-Inverting
- HighSideVoltage-Max(Bootstrap): 600 V
- Rise/FallTime(Typ): 40ns, 20ns
- OperatingTemperature: -40°C ~ 150°C (TJ)
- MountingType: Through Hole
- Package/Case: 14-DIP (0.300, 7.62mm)
- IR21824 Infineon, IC GATE DRVR HALF-BRIDGE 14DIP, Integrated Circuits (ICs)~PMIC - Gate Drivers
