IPP12CN10LGXKSA1 Images
- Manufacturer: Infineon Technologies
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: PG-TO220-3
- Description: MOSFET N-CH 100V 69A TO220-3
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
IPP12CN10LGXKSA1 Specifications:
- MfrPart.: IPP12CN10LGXKSA1
- Mfr: Infineon Technologies
- Description: MOSFET N-CH 100V 69A TO220-3
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tube
- Series: OptiMOS™
- PartStatus: Active
- FETType: N-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 100 V
- Current-ContinuousDrain(Id)@25°C: 69A (Tc)
- DriveVoltage(MaxRdsOnMinRdsOn): 4.5V, 10V
- RdsOn(Max)@IdVgs: 12mOhm @ 69A, 10V
- Vgs(th)(Max)@Id: 2.4V @ 83µA
- GateCharge(Qg)(Max)@Vgs: 58 nC @ 10 V
- Vgs(Max): ±20V
- InputCapacitance(Ciss)(Max)@Vds: 5600 pF @ 50 V
- FETFeature: -
- PowerDissipation(Max): 125W (Tc)
- OperatingTemperature: -55°C ~ 175°C (TJ)
- MountingType: Through Hole
- SupplierDevicePackage: PG-TO220-3
- IPP12CN10LGXKSA1 Infineon, MOSFET N-CH 100V 69A TO220-3, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
