IPN70R1K4P7SATMA1 Images
- Manufacturer: Infineon Technologies
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: PG-SOT223
- Description: MOSFET N-CHANNEL 700V 4A SOT223
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
IPN70R1K4P7SATMA1 Specifications:
- MfrPart.: IPN70R1K4P7SATMA1
- Mfr: Infineon Technologies
- Description: MOSFET N-CHANNEL 700V 4A SOT223
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tape & Reel (TR),Cut Tape (CT)
- Series: CoolMOS™ P7
- PartStatus: Active
- FETType: N-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 700 V
- Current-ContinuousDrain(Id)@25°C: 4A (Tc)
- DriveVoltage(MaxRdsOnMinRdsOn): 10V
- RdsOn(Max)@IdVgs: 1.4Ohm @ 700mA, 10V
- Vgs(th)(Max)@Id: 3.5V @ 40µA
- GateCharge(Qg)(Max)@Vgs: 4.7 nC @ 10 V
- Vgs(Max): ±16V
- InputCapacitance(Ciss)(Max)@Vds: 158 pF @ 400 V
- FETFeature: -
- PowerDissipation(Max): 6.2W (Tc)
- OperatingTemperature: -40°C ~ 150°C (TJ)
- MountingType: Surface Mount
- SupplierDevicePackage: PG-SOT223
- IPN70R1K4P7SATMA1 Infineon, MOSFET N-CHANNEL 700V 4A SOT223, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
IPN70R1K4P7SATMA1, Infineon authentic parts in stock from Infineon authorized distributors, order today, can ship immediately.
