IPDH4N03LAG Images
- Manufacturer: Infineon Technologies
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: PG-TO252-3-11
- Description: MOSFET N-CH 25V 90A TO252-3
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
IPDH4N03LAG Specifications:
- MfrPart.: IPDH4N03LAG
- Mfr: Infineon Technologies
- Description: MOSFET N-CH 25V 90A TO252-3
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tape & Reel (TR),Cut Tape (CT)
- Series: OptiMOS™
- PartStatus: Obsolete
- FETType: N-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 25 V
- Current-ContinuousDrain(Id)@25°C: 90A (Tc)
- DriveVoltage(MaxRdsOnMinRdsOn): 4.5V, 10V
- RdsOn(Max)@IdVgs: 4.2mOhm @ 60A, 10V
- Vgs(th)(Max)@Id: 2V @ 40µA
- GateCharge(Qg)(Max)@Vgs: 26 nC @ 5 V
- Vgs(Max): ±20V
- InputCapacitance(Ciss)(Max)@Vds: 3200 pF @ 15 V
- FETFeature: -
- PowerDissipation(Max): 94W (Tc)
- OperatingTemperature: -55°C ~ 175°C (TJ)
- MountingType: Surface Mount
- SupplierDevicePackage: PG-TO252-3-11
- IPDH4N03LAG Infineon, MOSFET N-CH 25V 90A TO252-3, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
IPDH4N03LAG, Infineon authentic parts in stock from Infineon authorized distributors, order today, can ship immediately.
