IPB80N06S3L-05 Images
- Manufacturer: Infineon Technologies
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: PG-TO263-3-2
- Description: MOSFET N-CH 55V 80A TO263-3
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
IPB80N06S3L-05 Specifications:
- MfrPart.: IPB80N06S3L-05
- Mfr: Infineon Technologies
- Description: MOSFET N-CH 55V 80A TO263-3
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tape & Reel (TR),Cut Tape (CT)
- Series: OptiMOS™
- PartStatus: Obsolete
- FETType: N-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 55 V
- Current-ContinuousDrain(Id)@25°C: 80A (Tc)
- DriveVoltage(MaxRdsOnMinRdsOn): 5V, 10V
- RdsOn(Max)@IdVgs: 4.5mOhm @ 69A, 10V
- Vgs(th)(Max)@Id: 2.2V @ 115µA
- GateCharge(Qg)(Max)@Vgs: 273 nC @ 10 V
- Vgs(Max): ±16V
- InputCapacitance(Ciss)(Max)@Vds: 13060 pF @ 25 V
- FETFeature: -
- PowerDissipation(Max): 165W (Tc)
- OperatingTemperature: -55°C ~ 175°C (TJ)
- MountingType: Surface Mount
- SupplierDevicePackage: PG-TO263-3-2
- IPB80N06S3L-05 Infineon, MOSFET N-CH 55V 80A TO263-3, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
IPB80N06S3L-05, Infineon authentic parts in stock from Infineon authorized distributors, order today, can ship immediately.
