IPB156N22NFDATMA1 Images
- Manufacturer: Infineon Technologies
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: PG-TO263-3-2
- Description: IPB156N22 - OPTIMOS, 220V FD POW
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
IPB156N22NFDATMA1 Specifications:
- MfrPart.: IPB156N22NFDATMA1
- Mfr: Infineon Technologies
- Description: IPB156N22 - OPTIMOS, 220V FD POW
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Bulk
- Series: OptiMOS™FD
- PartStatus: Active
- FETType: N-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 220 V
- Current-ContinuousDrain(Id)@25°C: 72A (Tc)
- DriveVoltage(MaxRdsOnMinRdsOn): 10V
- RdsOn(Max)@IdVgs: 15.6mOhm @ 50A, 10V
- Vgs(th)(Max)@Id: 4V @ 270µA
- GateCharge(Qg)(Max)@Vgs: 87 nC @ 10 V
- Vgs(Max): ±20V
- InputCapacitance(Ciss)(Max)@Vds: 6.93 pF @ 110 V
- FETFeature: -
- PowerDissipation(Max): 300W (Tc)
- OperatingTemperature: -55°C ~ 175°C (TJ)
- MountingType: Surface Mount
- SupplierDevicePackage: PG-TO263-3-2
- IPB156N22NFDATMA1 Infineon, IPB156N22 - OPTIMOS, 220V FD POW, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
