IMW120R045M1XKSA1 Images
- Manufacturer: Infineon Technologies
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: PG-TO247-3-41
- Description: SICFET N-CH 1.2KV 52A TO247-3
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
IMW120R045M1XKSA1 Specifications:
- MfrPart.: IMW120R045M1XKSA1
- Mfr: Infineon Technologies
- Description: SICFET N-CH 1.2KV 52A TO247-3
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tube
- Series: CoolSiC™
- PartStatus: Active
- FETType: N-Channel
- Technology: SiCFET (Silicon Carbide)
- DraintoSourceVoltage(Vdss): 1.2 kV
- Current-ContinuousDrain(Id)@25°C: 52A (Tc)
- DriveVoltage(MaxRdsOnMinRdsOn): 15V
- RdsOn(Max)@IdVgs: 59mOhm @ 20A, 15V
- Vgs(th)(Max)@Id: 5.7V @ 10mA
- GateCharge(Qg)(Max)@Vgs: 52 nC @ 15 V
- Vgs(Max): +20V, -10V
- InputCapacitance(Ciss)(Max)@Vds: 1.9 nF @ 800 V
- FETFeature: -
- PowerDissipation(Max): 228W (Tc)
- OperatingTemperature: -55°C ~ 175°C (TJ)
- MountingType: Through Hole
- SupplierDevicePackage: PG-TO247-3-41
- IMW120R045M1XKSA1 Infineon, SICFET N-CH 1.2KV 52A TO247-3, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
