IMBG120R140M1HXTMA1 Images
- Manufacturer: Infineon Technologies
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: PG-TO263-7-12
- Description: TRANS SJT N-CH 1.2KV 18A TO263
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
IMBG120R140M1HXTMA1 Specifications:
- MfrPart.: IMBG120R140M1HXTMA1
- Mfr: Infineon Technologies
- Description: TRANS SJT N-CH 1.2KV 18A TO263
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tape & Reel (TR),Cut Tape (CT)
- Series: CoolSiC™
- PartStatus: Active
- FETType: N-Channel
- Technology: SiC (Silicon Carbide Junction Transistor)
- DraintoSourceVoltage(Vdss): 1.2 kV
- Current-ContinuousDrain(Id)@25°C: 18A (Tc)
- DriveVoltage(MaxRdsOnMinRdsOn): -
- RdsOn(Max)@IdVgs: 189mOhm @ 6A, 18V
- Vgs(th)(Max)@Id: 5.7V @ 2.5mA
- GateCharge(Qg)(Max)@Vgs: 13.4 nC @ 18 V
- Vgs(Max): +18V, -15V
- InputCapacitance(Ciss)(Max)@Vds: 491 pF @ 800 V
- FETFeature: Standard
- PowerDissipation(Max): 107W (Tc)
- OperatingTemperature: -55°C ~ 175°C (TJ)
- MountingType: Surface Mount
- SupplierDevicePackage: PG-TO263-7-12
- IMBG120R140M1HXTMA1 Infineon, TRANS SJT N-CH 1.2KV 18A TO263, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
