IHW40T120FKSA1 Images
- Manufacturer: Infineon Technologies
- Category: Discrete Semiconductor Products~Transistors - IGBTs - Single Package/Case: TO-247-3
- Description: IGBT, 75A, 1200V, N-CHANNEL
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
IHW40T120FKSA1 Specifications:
- MfrPart.: IHW40T120FKSA1
- Mfr: Infineon Technologies
- Description: IGBT, 75A, 1200V, N-CHANNEL
- Product Category: Discrete Semiconductor Products~Transistors - IGBTs - Single
- Package: Tube
- Series: TrenchStop®
- PartStatus: Obsolete
- IGBTType: Trench Field Stop
- Voltage-CollectorEmitterBreakdown(Max): 1.2 kV
- Current-Collector(Ic)(Max): 75 A
- Current-CollectorPulsed(Icm): 105 A
- Vce(on)(Max)@VgeIc: 2.3V @ 15V, 40A
- Power-Max: 270 W
- SwitchingEnergy: 6.5mJ
- InputType: Standard
- GateCharge: 203 nC
- Td(on/off)@25°C: 48ns/480ns
- TestCondition: 600V, 40A, 15Ohm, 15V
- ReverseRecoveryTime(trr): 195 ns
- OperatingTemperature: -40°C ~ 150°C (TJ)
- MountingType: Through Hole
- Package/Case: TO-247-3
- IHW40T120FKSA1 Infineon, IGBT, 75A, 1200V, N-CHANNEL, Discrete Semiconductor Products~Transistors - IGBTs - Single
IHW40T120FKSA1, Infineon authentic parts in stock from Infineon authorized distributors, order today, can ship immediately.
