IGP03N120H2 Images
- Manufacturer: Infineon Technologies
- Category: Discrete Semiconductor Products~Transistors - IGBTs - Single Package/Case: TO-220-3
- Description: IGBT, 9.6A, 1200V, N-CHANNEL
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
IGP03N120H2 Specifications:
- MfrPart.: IGP03N120H2
- Mfr: Infineon Technologies
- Description: IGBT, 9.6A, 1200V, N-CHANNEL
- Product Category: Discrete Semiconductor Products~Transistors - IGBTs - Single
- Package: Bulk
- Series: -
- PartStatus: Active
- IGBTType: -
- Voltage-CollectorEmitterBreakdown(Max): 1.2 kV
- Current-Collector(Ic)(Max): 9.6 A
- Current-CollectorPulsed(Icm): 9.9 A
- Vce(on)(Max)@VgeIc: 2.8V @ 15V, 3A
- Power-Max: 62.5 W
- SwitchingEnergy: 290µJ
- InputType: Standard
- GateCharge: 22 nC
- Td(on/off)@25°C: 9.2ns/281ns
- TestCondition: 800V, 3A, 82Ohm, 15V
- ReverseRecoveryTime(trr): -
- OperatingTemperature: -40°C ~ 150°C (TJ)
- MountingType: Through Hole
- Package/Case: TO-220-3
- IGP03N120H2 Infineon, IGBT, 9.6A, 1200V, N-CHANNEL, Discrete Semiconductor Products~Transistors - IGBTs - Single
IGP03N120H2, Infineon authentic parts in stock from Infineon authorized distributors, order today, can ship immediately.
