IGP01N120H2XKSA1 Images
- Manufacturer: Infineon Technologies
- Category: Discrete Semiconductor Products~Transistors - IGBTs - Single Package/Case: TO-220-3
- Description: IGBT 1200V 3.2A 28W TO220-3
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
IGP01N120H2XKSA1 Specifications:
- MfrPart.: IGP01N120H2XKSA1
- Mfr: Infineon Technologies
- Description: IGBT 1200V 3.2A 28W TO220-3
- Product Category: Discrete Semiconductor Products~Transistors - IGBTs - Single
- Package: Tube
- Series: -
- PartStatus: Obsolete
- IGBTType: -
- Voltage-CollectorEmitterBreakdown(Max): 1200 V
- Current-Collector(Ic)(Max): 3.2 A
- Current-CollectorPulsed(Icm): 3.5 A
- Vce(on)(Max)@VgeIc: 2.8V @ 15V, 1A
- Power-Max: 28 W
- SwitchingEnergy: 140µJ
- InputType: Standard
- GateCharge: 8.6 nC
- Td(on/off)@25°C: 13ns/370ns
- TestCondition: 800V, 1A, 241Ohm, 15V
- ReverseRecoveryTime(trr): -
- OperatingTemperature: -40°C ~ 150°C (TJ)
- MountingType: Through Hole
- Package/Case: TO-220-3
- IGP01N120H2XKSA1 Infineon, IGBT 1200V 3.2A 28W TO220-3, Discrete Semiconductor Products~Transistors - IGBTs - Single
IGP01N120H2XKSA1, Infineon authentic parts in stock from Infineon authorized distributors, order today, can ship immediately.
