DF80R12W2H3FB11BPSA1 Images
- Manufacturer: Infineon Technologies
- Category: Discrete Semiconductor Products~Transistors - IGBTs - Modules Package/Case: Module
- Description: IGBT MOD 1200V 20A 20MW
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
DF80R12W2H3FB11BPSA1 Specifications:
- MfrPart.: DF80R12W2H3FB11BPSA1
- Mfr: Infineon Technologies
- Description: IGBT MOD 1200V 20A 20MW
- Product Category: Discrete Semiconductor Products~Transistors - IGBTs - Modules
- Package: Tray
- Series: EconoPACK™2
- PartStatus: Active
- IGBTType: Trench Field Stop
- Configuration: Half Bridge
- Voltage-CollectorEmitterBreakdown(Max): 1200 V
- Current-Collector(Ic)(Max): 20 A
- Power-Max: 20 mW
- Vce(on)(Max)@VgeIc: 1.7V @ 15V, 20A
- Current-CollectorCutoff(Max): 1 mA
- InputCapacitance(Cies)@Vce: 2.35 nF @ 25 V
- Input: Standard
- NTCThermistor: Yes
- OperatingTemperature: -40°C ~ 150°C (TJ)
- MountingType: Chassis Mount
- Package/Case: Module
- DF80R12W2H3FB11BPSA1 Infineon, IGBT MOD 1200V 20A 20MW, Discrete Semiconductor Products~Transistors - IGBTs - Modules
