BTS7960P Images
- Manufacturer: Infineon Technologies
- Category: Integrated Circuits (ICs)~PMIC - Full, Half-Bridge Drivers Package/Case: TO-220-7 (Formed Leads)
- Description: IC NOVALITHIC 1/2 BRIDGE TO220-7
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
BTS7960P Specifications:
- MfrPart.: BTS7960P
- Mfr: Infineon Technologies
- Description: IC NOVALITHIC 1/2 BRIDGE TO220-7
- Product Category: Integrated Circuits (ICs)~PMIC - Full, Half-Bridge Drivers
- Package: Tube
- Series: NovalithIC™
- PartStatus: Obsolete
- OutputConfiguration: Half Bridge
- Applications: DC Motors, General Purpose
- Interface: Logic
- LoadType: Inductive
- Technology: DMOS
- RdsOn(Typ): 9mOhm LS, 7mOhm HS
- Current-Output/Channel: 40A
- Current-PeakOutput: 60A
- Voltage-Supply: 5.5V ~ 27.5V
- Voltage-Load: 5.5V ~ 27.5V
- OperatingTemperature: -40°C ~ 150°C (TJ)
- Features: Latch Function, Slew Rate Controlled, Status Flag
- FaultProtection: Current Limiting, Over Temperature, Short Circuit, UVLO
- MountingType: Through Hole
- Package/Case: TO-220-7 (Formed Leads)
- BTS7960P Infineon, IC NOVALITHIC 1/2 BRIDGE TO220-7, Integrated Circuits (ICs)~PMIC - Full, Half-Bridge Drivers
BTS7960P, Infineon authentic parts in stock from Infineon authorized distributors, order today, can ship immediately.
