BTS7750GP Images
- Manufacturer: Infineon Technologies
- Category: Integrated Circuits (ICs)~PMIC - Full, Half-Bridge Drivers Package/Case: TO-263-18 (15 Leads + 3 Tabs)
- Description: IC TRILITHIC SWITCH D2PAK-15
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
BTS7750GP Specifications:
- MfrPart.: BTS7750GP
- Mfr: Infineon Technologies
- Description: IC TRILITHIC SWITCH D2PAK-15
- Product Category: Integrated Circuits (ICs)~PMIC - Full, Half-Bridge Drivers
- Package: Tape & Reel (TR)
- Series: TrilithIC™
- PartStatus: Obsolete
- OutputConfiguration: Half Bridge (2)
- Applications: DC Motors, General Purpose
- Interface: Logic
- LoadType: Inductive
- Technology: DMOS
- RdsOn(Typ): 45mOhm LS, 70mOhm HS
- Current-Output/Channel: -
- Current-PeakOutput: 12A
- Voltage-Supply: 1.8V ~ 42V
- Voltage-Load: 1.8V ~ 42V
- OperatingTemperature: -40°C ~ 150°C (TJ)
- Features: Status Flag
- FaultProtection: ESD, Over Temperature, Short Circuit, UVLO
- MountingType: Surface Mount
- Package/Case: TO-263-18 (15 Leads + 3 Tabs)
- BTS7750GP Infineon, IC TRILITHIC SWITCH D2PAK-15, Integrated Circuits (ICs)~PMIC - Full, Half-Bridge Drivers
BTS7750GP, Infineon authentic parts in stock from Infineon authorized distributors, order today, can ship immediately.
