BSZ520N15NS3GATMA1 Images
- Manufacturer: Infineon Technologies
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: PG-TSDSON-8
- Description: MOSFET N-CH 150V 21A 8TSDSON
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
BSZ520N15NS3GATMA1 Specifications:
- MfrPart.: BSZ520N15NS3GATMA1
- Mfr: Infineon Technologies
- Description: MOSFET N-CH 150V 21A 8TSDSON
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tape & Reel (TR),Cut Tape (CT)
- Series: OptiMOS™
- PartStatus: Active
- FETType: N-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 150 V
- Current-ContinuousDrain(Id)@25°C: 21A (Tc)
- DriveVoltage(MaxRdsOnMinRdsOn): 8V, 10V
- RdsOn(Max)@IdVgs: 52mOhm @ 18A, 10V
- Vgs(th)(Max)@Id: 4V @ 35µA
- GateCharge(Qg)(Max)@Vgs: 12 nC @ 10 V
- Vgs(Max): ±20V
- InputCapacitance(Ciss)(Max)@Vds: 890 pF @ 75 V
- FETFeature: -
- PowerDissipation(Max): 57W (Tc)
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Surface Mount
- SupplierDevicePackage: PG-TSDSON-8
- BSZ520N15NS3GATMA1 Infineon, MOSFET N-CH 150V 21A 8TSDSON, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
